Kirisun PT8000
Professional Mobile Radio
PT8000 with compact size is flexible to install in the vehicle when space is limited.
Each channel or all channels could be set to high or low RF power for different applications by programming software or manually.
With wide band frequency coverage including 136-174M, 438-490M, 400-450M, 470-512M, it is flexible for different market use.
DTMF encode and decode function provide use for dispatch operations and remote control applications.
If the radio is killed, all the attempts on operation by user, except power on/off, will be ignored. The radio will be activated when received the activated code. It is very useful for radio when lost. This function insure you high security communication.
The PA feature feeds MIC audio through a powerful external public address amplifier, and outputs through external speaker, offering robust clarity in harsh, noisy environments.
The radio can be programmed to alarm local or secretly, to alarm with sending emergency code and alert or background sound for different emergency environments,
A certain code could be programmed with press or/and release of PTT button to notify the other people who is the caller.
The radio enters emergency mode if the user does not respond to a warning call (Lone Work) or a inquire code (Security Check), adding security and safety for individuals who work remotely and lonely. To prevent any carelessly missing, the reset of lone work status could be by simply press on programmed key.
Background sound could be monitored by remote receiver with specific code.
Up to 5 programmable keys could be set as different functions including talk around, lone work, emergency call, scan, power level, monitor, squelch level and so on.
Frequency | 136~174MHz, 400-450MHz, 438~490MHz, 470~512MHz |
---|---|
Channel Capacity | 8 |
Channel Spacing | 12.5KHz, 25KHz |
Operating Temperature | -30℃~ +60℃ |
Operating Voltage | 13.6V DC ±20% |
Frequency Stability | ±2.5 ppm |
Dimension (mm) | 150 ×129 × 43 |
Weight (g) | 1310 |
RF Power Output | 25W/5W(UHF), 25W/5W(VHF) |
---|---|
Frequency Modulation | 16K φ F3E, 11K φ F3E |
Antenna Impedance | 50Ω |
Modulation Limiting | ±2.5KHz@12.5KHz, ±5KHz@25KHz |
Radiated Spurious Emission | -36dBm < 1GHz, -30dBm > 1GHz |
FM Noise | 45dB @ 25KHz |
Modulation Distortion | 5M< 3% hz |
Reference Sensitivity | 0.28μV @ 12.5KHz, 0.25μV @ 25KHz |
---|---|
Adjacent channel Selectivity | 60dB @ 12.5KHz, 70dB @ 20/25KHz |
Intermodulation | 65dB |
Spurious Response Rejection | 70dB |
Rated Audio Output | 4W |
S/N | 40/35 |
Rated Audio Distortion | ≤3% |
